Main Technical Specifications
|
|
Drilling Rod(mm): Φ73 Φ89 Φ127
|
|
Drill Depth(m); 1300-1000
|
|
Throughout Dia. of Rotary Table(mm): Φ435
|
|
Rotating Speed(r/min) Forward and Reverse: 48, 69, 110, 190
|
|
Rated Torque(KN.m): 18, 12.5, 8, 4.5
|
|
Hoist
|
|
Rated hoisting Capacity of single Rope(KN): 80
|
|
Hoisting Speed(m/s): 0.84, 1.9. 3.3
|
|
Steel Wire Diameter: 6X19{mm)24
|
|
Cathead Unit When forks are not used, cathead and wrench can be used to screw and remove the drilling tool.
|
|
Water Brake Duplicating water brakes
|
|
Diameter of Impeller(mm): Φ 330
|
|
Big Hook
|
|
Pulley Block Type: 4x5
|
|
Rated Load of Big Hook(kN): 800
|
|
Hoisting Speed of Big Hook(m / s): 0.11, 0.24, 0.41
|
|
Kelly Bar: (mm x mm x mm) :108 x 108 x 12000
|
|
Power Engine
|
|
Diesel Engine 6135AN-1: 150HP / 1500r / min
|
|
Electric Motor Y315S—4: 110kw / 1500r / min
|
|
Mainbody Weight: about 7t (without power unit)
|
|
Dimensions(mm): 3880 x 1965 x 1290
|
|
Main Auxiliary Equipment
|
|
Drill tower:
|
|
Tetragonal type pipe-tower and "A"-type drill tower for Customers' choice
|
|
The drill tower has great loading capability and convenience for installation.
|
|
Nominal height of drill tower(m): 24, 27
|
|
Nominal square of base(m): 6.5 x 6.5 7 x 7
|
|
Max. working load of crane(kN): 680
|
|
Weight of drill tower(t): 10, 16t
|
|
Slurry system consists of BW—1200 slurry pump.power station and pump pipes
|
|
Pressure of Slurry Pump(Mpa): 3.2, 4.4, 6.2, 11
|
|
Discharging Volume(1: /Min): 1200, 900, 630, 360
|
|
Power of Engine: 75kw / 1480r / min, 100HP / 1500r / min
|
|
Inner diameter of water output hose(mm): Φ 75
|
