Drilling Rod(mm): Φ73 Φ89 Φ127
|
|
Drill Depth(m): 1600～2000
|
|
Throughout Dia. of Rotary Table(mm): Φ520 Φ605
|
|
Rotation Speed(r / min) Forward and reverse 25 , 37.3 , 55.5 , 87.3, 130.2, 193.7
|
|
Rated Torque(KN. m): 25
|
|
Hoist
|
|
Rated Hoisting Capacity of Single Rope(KN): 85
|
|
Hoisting Speed(m/s): 0.84, 1.24, 1.86, 2.92, 4.36, 6.49
|
|
Steel wire diameter: 6x19(mm) Φ24
|
|
Big Hook
|
|
Pulley Block Type: 4x5
|
|
Rated Load of Big Hook(kN): 680
|
|
Hoisting Speed of Big Hook(in/s): 0.105, 0.155, 0.23
|
|
Kelly Bar: (mm x mm x mm) : 121 x 121 x 12200 108x108x12200
|
|
Power Engine
|
|
Diesel Engine WD615T1: 120kw/1500r/min
|
|
Electric motor Y315S—4: 110kw/ 1500r / min
|
|
Mainbody Weight: about 7.5t
|
|
Main Auxiliary Equipment
|
|
1.
|
Drill tower:
|
|
Tetragonal pipe-tower and "A" -type drill tower for customers' choice
|
|
The drill tower has great loading capability and convenience for installation.
|
|
Nominal height of drill tower(m): 24, 27
|
|
Nominal square of base(m): 6.5 x 6.5 7 x 7
|
|
Max.working load of crane(kN): 680 Weight of drill tower(t): 10, 16
|
|
2.
|
Slurry system consists of BW—1200 type slurry pump, power station and pump pipes.
|
|
Pressure of Slurry Pump(Mpa): 3.2, 4.4, 6.2, 11
|
|
Discharging Volume(1: /Min): 1200, 900 , 630 , 360
|
|
Power of Engine: 75kw/1480r/min, 100HP/1500r/rain
|
|
Inner diameter of water output hose(mm): Φ75
|
|
3.
|
Travelling Block four-pulley hook
|
|
Rated load capability(kN): 500-800
|
|
4.
|
Swivel
|
|
Max.load(kN): 800 Inner diameter of water inlet hose(mm): Φ75
|
