Basic specification
|
|
Drill depth(m): 2000-3000
|
|
Drilling Rod(mm): Φ73 Φ89 Φ127
|
|
Engine Power
|
|
Type: Y315-4(motor) 2(sets)
|
|
Power: 110kw x 2
|
|
Rotation speed: 1480r/min
|
|
Hydraulic Coupling
|
|
Type: YL500X1 2(sets)
|
|
Input rotation speed: 1475r/min
|
|
Transmission power: 90-l32kw
|
|
Power: 0.97
|
|
Filled liquid volume: 16.5L
|
|
Rotary-table
|
|
Type: ZP-175
|
|
Rating net load: 272t
|
|
Max.rotation speed: 350r/min
|
|
Opening Diameter: 445mm
|
|
Transmission ratio: 3.75: 1
|
|
Rotation speed of Rotary-table: Forwards and Reverse 33 58 75 132 r/ rain
|
|
Rating Max.torque of rotary-table: 40 kN.m
|
|
Kelly Bar: 108 x 108 x 12200 133 x 133 x 12200
|
|
|
|
Hoist
|
|
Hoist capability of single(second floor): 100, 57.24, 44.35, 25.36 kN
|
|
Hoist capability of big hook(5x 6): 950kN
|
|
Hoist speed of big hook(5x6): 0.1715, 0.3, 0.3868, 0.677 m/s
|
|
Rotation speed of cathead wheel: 90, 158, 203, 356r/min
|
|
Height of drill tower: 31m
|
|
Max.net load of crane: 130t
|
|
Overall Weight: 21t
|
