Hole diameter (mm): Φ100-Φ210

Hole depth (m): 50-80

Rod diameter (mm): Φ89, Φ102, Φ114

Hole angle (°): -10-90

Output rotary speed of power head (r/min):16, 30, 38, 55, 75, 105

Output torque of power head (N.m): 4200

Stroke of power head (mm): 1800

Stroke of the Slide Frame (mm): 600

Lifting force of power head (kN): 65

Lifting speed of power head (m/min): 0-1timing, 1, 7.5, 8.5

Feeding force of power head (kN): 33

Feeding speed of power head(m/min): 0-2timing, 14.5, 16.5

Input power (electromotor, kW): 30+1.5+0.25(radiator)

Dimensions:
Mainframe: Working station(L×W×H, mm):2200×650×3400
Transport station(L×W×H, mm): 3400×650×1500

Weight (kg): 2600

Remark: Technical specifications are subject to change without prior notice and incurring responsibility for machines previously sold. The shown machines may have optional equipment. Technical data do not consider power losses.
