| 耐磨零件-->>拉伸模
HCE 型 HCF 型 |
|
|
单位：mm |
| HCE型(黑色金属圆管拉伸模) |
型号 |
基本尺寸 |
d02 |
h02 |
d01 |
l03 |
l04 |
R02 |
2αo |
HCE25- |
25.00 |
20.00 |
3.80~4.70 |
1.70 |
3.00 |
3.00 |
24 |
HCE30- |
30.00 |
24.00 |
5.70~7.70 |
2.10 |
3.50 |
4.00 |
HCE35- |
35.00 |
9.70~10.70 |
HCE40- |
40.00 |
11.70~13.70 |
HCE45- |
45.00 |
25.00 |
15.60~18.60 |
2.60 |
4.00 |
5.00 |
HCE50- |
50.00 |
20.60~22.60 |
HCE55- |
55.00 |
27.00 |
24.60~26.60 |
3.20 |
4.50 |
6.00 |
HCE60- |
60.00 |
28.60~30.60 |
HCE65- |
65.00 |
32.60~34.60 |
HCE70- |
70.00 |
30.00 |
36.50~38.50 |
4.00 |
5.50 |
HCE75- |
75.00 |
40.50~42.50 |
HCE80- |
80.00 |
45.00 |
|
| |
| HCF型(有色金属圆管拉伸模) 单位： mm |
型号 |
基本尺寸 |
d02 |
h02 |
d01 |
l03 |
l04 |
R02 |
2αo |
HCF20- |
20.00 |
17.00 |
2.80~3.80 |
1.50 |
2.50 |
2.00 |
24 |
HCF25- |
25.00 |
20.00 |
4.70~5.70 |
HCF30- |
30.00 |
24.00 |
6.70~8.70 |
2.00 |
3.00 |
3.00 |
HCF35- |
35.00 |
10.70~12.70 |
HCF40- |
40.00 |
14.70 |
4.00 |
HCF45- |
45.00 |
25.00 |
19.00~21.60 |
2.40 |
3.50 |
HCF50- |
50.00 |
23.60~25.60 |
5.00 |
HCF55- |
55.00 |
27.00 |
27.60~29.60 |
HCF60- |
60.00 |
31.60~33.00 |
2.80 |
4.00 |
6.00 |
HCF65- |
65.00 |
33.60~37.60 |
HCF70- |
70.00 |
30.00 |
31.50~47.50 |
3.20 |
5.00 |
HCF75- |
75.00 |
42.50~44.50 |
HCF80- |
80.00 |
47.00 |
HCF85- |
85.00 |
33.00 |
49.50~51.00 |
HCF90- |
90.00 |
53.00 |
|
|
|
|
