| 棒材-->>立铣刀圆形精磨棒 |
| |
|
|
单位：mm |
|
直径D |
长度L |
倒角 |
长度公差代码 |
|
D inch |
D mm |
L inch |
L mm |
B inch |
B mm |
c°de |
|
1/8 |
3.175 |
1 1/2 |
38.1 |
0.015 |
0.381 |
S |
|
2 |
50.8 |
|
3 |
76.2 |
T |
|
3/16 |
4.763 |
1 1/2 |
38.1 |
0.015 |
0.381 |
S |
|
2 |
50.8 |
|
2 1/2 |
63.5 |
U |
|
3 |
76.2 |
T |
|
1/4 |
6.350 |
1 1/2 |
38.1 |
0.025 |
0.635 |
S |
|
2 |
50.8 |
|
2 1/2 |
63.5 |
U |
|
3 |
76.2 |
T |
|
3 1/4 |
82.6 |
|
3 1/2 |
88.9 |
|
4 |
101.6 |
|
5/16 |
7.938 |
2 |
50.8 |
0.025 |
0.635 |
S |
|
2 1/2 |
63.5 |
U |
|
3 |
76.2 |
T |
|
3 1/2 |
88.9 |
|
4 |
101.6 |
|
3/8 |
9.525 |
2 |
50.8 |
0.030 |
0.762 |
S |
|
2 1/2 |
63.5 |
U |
|
3 |
76.2 |
T |
|
3 1/4 |
82.6 |
|
3 1/2 |
88.0 |
|
4 |
101.6 |
|
6 |
152.4 |
|
7/16 |
11.113 |
2 1/2 |
63.5 |
0.030 |
0.762 |
U |
|
2 3/4 |
69.9 |
|
4 |
101.6 |
T |
|
4 1/2 |
114.3 |
|
5 |
127.0 |
|
1/2 |
12.700 |
2 1/2 |
63.5 |
0.030 |
0.762 |
U |
|
3 |
76.2 |
T |
|
3 1/8 |
79.4 |
|
4 |
101.6 |
|
4 1/2 |
114.3 |
|
5 |
127 |
|
6 |
152.4 |
|
9/16 |
14.288 |
3 |
76.2 |
0.030 |
0.762 |
T |
|
3 1/2 |
88.9 |
|
5/8 |
15.875 |
3 |
76.2 |
0.030 |
0.762 |
T |
|
3 1/2 |
88.9 |
|
3 3/4 |
95.3 |
|
4 1/8 |
104.8 |
|
5 |
127 |
|
8 |
203.2 |
|
3/4 |
19.050 |
3 |
76.2 |
0.040 |
1.016 |
T |
|
3 1/2 |
88.9 |
|
4 |
101.6 |
|
4 1/2 |
114.3 |
|
5 |
127 |
|
6 |
152.4 |
|
6 1/2 |
165.1 |
|
7/8 |
22.225 |
4 |
101.6 |
0.040 |
1.016 |
T |
|
1 |
25.400 |
3 |
76.2 |
0.040 |
1.016 |
T |
|
3 1/2 |
88.9 |
|
4 |
101.6 |
|
5 |
127 |
|
6 |
152.4 |
|
7 |
177.8 |
|
1 1/4 |
31.750 |
4 1/2 |
114.3 |
0.040 |
1.016 |
T |
|
6 |
152.4 |
|
7 1/2 |
190.5 |
|
|
|
|
