| Cutting Tools--->> Mechanically Clamped Inserts
HC4N |
|
| For making drills with coolant channels,core drills and spiral corn milling cutters |
|
| |
Type |
Dimension(mm) |
Approx unit weight(g) |
d |
s |
r |
d1 |
H |
YG6 |
YG8 |
YT5 |
YT14 |
HC41005N |
10.0 |
3.5 |
0.5 |
4.2 |
10.0 |
4.3 |
4.2 |
3.7 |
3.3 |
HC41305N |
13.0 |
4.5 |
0.5 |
5.2 |
13.0 |
9.9 |
9.7 |
8.3 |
7.3 |
HC41605N |
16.0 |
5.5 |
0.5 |
6.2 |
16.0 |
18.2 |
17.9 |
15.7 |
13.9 |
HC41620N |
16.0 |
5.5 |
2.0 |
6.2 |
16.0 |
17.8 |
17.4 |
15.4 |
13.7 |
HC41910N |
19.0 |
7.0 |
1.0 |
7.2 |
19.0 |
32.5 |
32.0 |
28.0 |
24.8 |
|
|
|
|
