Hard-facing Materials--->> Cast Tungsten Carbide(YZNF)


1. Binay eutectic tungsten carbide(WC.W2C)

2. Particle size distribution:ranged from 20 microns to 8mm,powder of single or mixed particle size are available

3. Mainly used for oil exploiting drill bit,PCD drill and other melt-penntration products.Also for hard-facing of steel-tooth drill bit,food/vegetable oil machinery and motor

Properties
Grade
Microhardness(Load 100 g)
Density(g/cm3)
YZNF
1500-2000
15.8-16.7

Grade & Chemical Compositions
Chemical compositions(%)Ti＋
T.C
F.C＋
Fe＋
Cr＋
V＋
Si＋
Ti＋
Mo+Co+Ni＋
YZNF
3.7゛4.2
0.15
2.0
0.5
0.2
0.1
0.3
0.8
