| Wearable parts-->> Drawing Dies HC13 |
|
|
Unit：mm |
Type |
Dimension |
D |
H |
d |
h |
h1 |
R |
αo |
HC13- |
30.00 |
21.00 |
3.70~9.60 |
1.50~4.00 |
3.00 |
5.00 |
14 |
40.00 |
25.00 |
10.00~15.00 |
5.00 |
4.00 |
16 |
50.00 |
28.00 |
16.00~24.50 |
5.50~6.00 |
4.50 |
60.00 |
35.00 |
25.00~34.50 |
7.00~7.50 |
6.00 |
6.00 |
18 |
75.00 |
35.50~43.50 |
8.00 |
90.00 |
45.00~57.00 |
9.00~10.00 |
20 |
110.00 |
40.00 |
59.00~69.00 |
10.00~11.00 |
140.00 |
50.00 |
71.00~84.00 |
12.00 |
|
|
|
|
